SKFWheel bearings

SKF Wheel bearing kit VKBA 6906

Front wheel bearing kit for the Toyota Hilux

Art. no.: VKBA 6906

€119excl. VAT

SKU SKF-VKBA6906

From the central warehouse — delivered next working day · Log in to see your branch’s delivery rounds.

Stock

Central warehouse · 70 · Next day

Oslo Alnabru5
Bergen Kokstad0
Trondheim Tiller0
Stockholm Västberga5
Gothenburg Hisings Backa8
Rotterdam Waalhaven6

SKF wheel bearing kit for the front axle of the Toyota Hilux. Key sizes: 54 mm bore, 96 mm outer diameter, 51 mm wide, 4 wheel-bolt holes. Sold per wheel, with a fastener set and a service booklet in the box.

Fits

Vehicles this part is listed for, with position and conditions.

1 vehicle

VehicleEnginekWYearsPositionNote

On the liftToyota Hilux VIII (AN120)2.4 2GD-FTV 150 hp2GD-FTV110 kW1102015–2024Front axleModel code GUN125. For vehicles with ABS. Two per axle.

Specifications

Wheel bearing

Inner diameter: 54mm
Outer diameter: 96mm
Width: 51mm
ABS encoder (magnetic): — No
Number of holes: 4
Wheel hub included: — No
Axle nut included: — No

Technology

Complete repair kits (VKBA/VKMC/VKMA)VKN tools

Numbers

OE numbers

Vehicle makers’ own part numbers this part replaces.

Maker	OE number
Toyota	43570-60010
Toyota	43570-60011
Toyota	90366-F0002
Toyota	90366-T0061

Kit contents

1×Bearing
1×Fastener set
1×Service book

Documents

FITSKF fitting instructions MI-537930Fitting instructionsen

Why this one

Complete repair kit

Comes with a fastener set and a service booklet; nothing used goes back on.

Key dimensions

54 mm bore, 96 mm outer diameter, 51 mm wide, 4 wheel-bolt holes.

Matching SKF tool

SKF names VKN 604 as the special tool for fitting this kit.

On the job

The job

VKBA 6906 replaces a worn front wheel bearing on the Toyota Hilux. SKF supplies it as a ready-to-fit unit matched to the original design, with the single-use parts the job calls for. A worn bearing shows up as a hum that rises with road speed and changes when the car loads up in a bend.

In the box and alongside

The kit comes with a fastener set and a service booklet, so no used fasteners go back on. SKF recommends its special tool VKN 604 for the job. SKF lists two per axle, and with the wheel off it is the moment to check the brake discs, pads, the CV joint boot and the other side's bearing.
