Brembo Brake disc 09.D307.11
280 mm vented front disc for the Fiat 124 Spider
- Art. no.
- 09.D307.11
- EAN
- 8020584239902
- 280mm
- 22mm
- Vented
SKU BRE-09D30711 · EAN 8020584239902
From the central warehouse — delivered next working day · Log in to see your branch’s delivery rounds.
Stock
Central warehouse · 74 · Next day
- Oslo Alnabru36
- Bergen Kokstad39
- Trondheim Tiller19
- Stockholm Västberga16
- Gothenburg Hisings Backa10
- Rotterdam Waalhaven21
Specifications
Brake disc
- Disc type
- Vented
- Diameter
- 280mm
- Thickness
- 22mm
- Minimum thickness
- 20mm
- Height
- 44mm
- Centering diameter
- 55mm
- Number of holes
- 4
- Coated (anti-corrosion)
- ✓ Yes
- High-carbon cast iron
- — No
Numbers
OE numbers
Vehicle makers’ own part numbers this part replaces.
| Maker | OE number |
|---|---|
| Fiat | 0006000612391 |
| Fiat | 6000612391 |
Cross-references
Equivalent parts from other brands.
| Brand | Art. no. |
|---|---|
| ATE | 24012203001 |
| febi bilstein | 170731 |
| Ferodo | DDF3293C |
| Meyle | 35155210046PD |
| Mintex | MDC2859C |
| Pagid | 56015 |
| Textar | 92301503 |
| Zimmermann | 370440020 |
Why this one
01
280 x 22 mm
Vented disc, 4 holes, 55 mm centre bore, minimum thickness 20 mm.
02
UV-painted finish
Painted hat and edges keep rust off the hub face and cooling vanes.
03
Sold as a pair
Two discs per box, enough for one axle.
On the job
The job it does
OE-equivalent vented disc for the front axle of the Fiat 124 Spider. New it measures 280 x 22 mm and it must be replaced at 20 mm. The geometry matches the original disc, so no changes are needed at the hub or caliper.
Fitting it
Discs are always changed in axle pairs, and this one comes as a pair in the box. Fit new front pads at the same time, clean the hub face back to bare metal and check the caliper slide pins. A brake fluid change is often due at the same visit.
