Brembo Brake pad set P 24 217
Rear pad set for the Ford Focus IV 1.0 EcoBoost
- Art. no.
- P 24 217
- EAN
- 8020584113110
- 123mm
- 14mm
- Acoustic
SKU BRE-P24217 · EAN 8020584113110
From the central warehouse — delivered next working day · Log in to see your branch’s delivery rounds.
Stock
Central warehouse · 183 · Next day
- Oslo Alnabru13
- Bergen Kokstad11
- Trondheim Tiller0
- Stockholm Västberga39
- Gothenburg Hisings Backa0
- Rotterdam Waalhaven35
Brembo Prime rear pad set for the Ford Focus IV 1.0 EcoBoost, 123 x 48 x 14 mm for the ATE caliper. It is supplied with an acoustic wear warning, and the box holds anti-squeal shims. The pads are directional, so mind the left and right marking.
Fits
Vehicles this part is listed for, with position and conditions.
1 vehicle
- Ford Focus IV (HN)1.0 B7DA 125 hpB7DA92 kW922018–2024Rear axle
Specifications
Brake pads
- Width
- 123mm
- Height
- 48mm
- Thickness
- 14mm
- Wear indicator
- Acoustic
- WVA number
- 22232, 22233, 22231
- Fitting kit included
- — No
- Chamfered / slotted
- — No
- Anti-squeal shims
- ✓ Yes
Technology
Numbers
OE numbers
Vehicle makers’ own part numbers this part replaces.
| Maker | OE number |
|---|---|
| Ford | 2209329 |
| Ford | 2247444 |
| Ford | 2367295 |
| Ford | 2379248 |
| Ford | 2433333 |
| Ford | 2493719 |
| Ford | 2494035 |
| Ford | BRF1954 |
| Ford | JX6Z2200E |
| Ford | KTJ1GC2M007AC |
| Ford | KTJX612M007ACC |
| Ford | KTJX612M007AEB |
Cross-references
Equivalent parts from other brands.
| Brand | Art. no. |
|---|---|
| ATE | 13046073462 |
| Bosch | 0986460179 |
| febi bilstein | 171393 |
| Ferodo | FDB5174 |
| Hella Pagid | 355037791 |
| Meyle | 0252223116 |
| Mintex | MDB4107 |
| Pagid | T2796 |
| Textar | 2223103 |
| TRW | GDB2115 |
Why this one
01
123x48x14 mm
Fits the ATE caliper, WVA 22232.
02
Wear indicator
With an acoustic wear warning.
03
Hardware included
Anti-squeal shims in the box.
04
ECE R90 approved
Prime friction material matched to the original pad for bite and wear.
On the job
The job it does
A complete rear axle set for the Ford Focus IV 1.0 EcoBoost. The pads measure 123 x 48 mm and are 14 mm thick, made to fit the ATE caliper, and the friction material is ECE R90 approved and matched to the original for bite and wear. The box includes anti-squeal shims, so worn hardware does not go back on.
Fitting it
Measure the discs while the wheels are off; if they are near the minimum thickness, replace them with the pads. A spring tab on the pad squeals against the disc when the lining gets thin. These are directional pads: follow the left/right marking. Clean and grease the caliper guides, push the piston back gently and bed the pads in with a few moderate stops.
