Brembo Brake disc 09.A634.11
297 mm vented front disc for the Toyota Hilux 2.4 D
- Art. no.
- 09.A634.11
- EAN
- 8020584021606
- 297mm
- 25mm
- Vented
SKU BRE-09A63411 · EAN 8020584021606
From the central warehouse — delivered next working day · Log in to see your branch’s delivery rounds.
Stock
Central warehouse · 91 · Next day
- Oslo Alnabru37
- Bergen Kokstad21
- Trondheim Tiller36
- Stockholm Västberga37
- Gothenburg Hisings Backa37
- Rotterdam Waalhaven15
Specifications
Brake disc
- Disc type
- Vented
- Diameter
- 297mm
- Thickness
- 25mm
- Minimum thickness
- 23mm
- Height
- 67mm
- Centering diameter
- 108mm
- Number of holes
- 6
- Coated (anti-corrosion)
- ✓ Yes
- High-carbon cast iron
- — No
Numbers
OE numbers
Vehicle makers’ own part numbers this part replaces.
| Maker | OE number |
|---|---|
| Toyota | 435120K060 |
| Toyota | 435120K070 |
| Toyota | 435120K250 |
Cross-references
Equivalent parts from other brands.
| Brand | Art. no. |
|---|---|
| ATE | 24012501921 |
| Bosch | 0986479A96 |
| febi bilstein | 108399 |
| Ferodo | DDF1783C |
| Meyle | 30155210126 |
| Mintex | MDC2184 |
| Pagid | 55226 |
Why this one
01
297 x 25 mm
Vented disc, 6 holes, 108 mm centre bore, minimum thickness 23 mm.
02
UV-painted finish
Painted hat and edges keep rust off the hub face and cooling vanes.
03
Sold as a pair
Two discs per box, enough for one axle.
On the job
The job it does
OE-equivalent vented disc for the front axle of the Toyota Hilux 2.4 D. New it measures 297 x 25 mm and it must be replaced at 23 mm. The geometry matches the original disc, so no changes are needed at the hub or caliper.
Fitting it
Discs are always changed in axle pairs, and this one comes as a pair in the box. Fit new front pads at the same time, clean the hub face back to bare metal and check the caliper slide pins. Brembo lists a tightening torque of 112 Nm. A brake fluid change is often due at the same visit.
