Brembo Brake disc 08.D046.11
298 mm solid rear disc for the Mercedes-Benz Sprinter 316 CDI
- Art. no.
- 08.D046.11
- EAN
- 8020584238875
- 298mm
- 18mm
- Solid
SKU BRE-08D04611 · EAN 8020584238875
From the central warehouse — delivered next working day · Log in to see your branch’s delivery rounds.
Stock
Central warehouse · 56 · Next day
- Oslo Alnabru27
- Bergen Kokstad12
- Trondheim Tiller0
- Stockholm Västberga35
- Gothenburg Hisings Backa8
- Rotterdam Waalhaven0
Brembo Prime 298 mm x 18 mm solid disc for the rear axle of the Mercedes-Benz Sprinter 316 CDI. UV-painted hat and edges, 6 holes and a 85 mm centre bore; replace at 16 mm. Sold as a pair, 2 discs per box.
Fits
Vehicles this part is listed for, with position and conditions.
1 vehicle
- Mercedes-Benz Sprinter 9072.1 OM651.958 163 hpOM651.958120 kW1202018–2024Rear axleFor cars with electric parking brake. Cars without electric parking brake take 08.9509.11.
Specifications
Brake disc
- Disc type
- Solid
- Diameter
- 298mm
- Thickness
- 18mm
- Minimum thickness
- 16mm
- Height
- 56mm
- Centering diameter
- 85mm
- Number of holes
- 6
- Coated (anti-corrosion)
- ✓ Yes
- High-carbon cast iron
- ✓ Yes
- Bolts included
- ✓ Yes
- Wheel bearing included
- — No
- Pieces per pack
- 2
Numbers
OE numbers
Vehicle makers’ own part numbers this part replaces.
| Maker | OE number |
|---|---|
| Mercedes-Benz | 9104232100 |
| Mercedes-Benz | 910423210007 |
| Mercedes-Benz | A9104232100 |
Cross-references
Equivalent parts from other brands.
| Brand | Art. no. |
|---|---|
| Bosch | 0986479H07 |
| febi bilstein | 175505 |
| Meyle | 0155231004PD |
| Mintex | MDC2850C |
| Pagid | 56010 |
| Textar | 92301003 |
| TRW | DF6596S |
| Zimmermann | 400554720 |
Why this one
01
298 x 18 mm
Solid disc, 6 holes, 85 mm centre bore, minimum thickness 16 mm.
02
UV-painted finish
Painted hat and edges keep rust off the hub face and cooling vanes.
03
High-carbon iron
Extra carbon damps vibration and helps the disc handle heat.
04
Sold as a pair
Two discs per box, enough for one axle.
On the job
The job it does
OE-equivalent solid disc for the rear axle of the Mercedes-Benz Sprinter 316 CDI. New it measures 298 x 18 mm and it must be replaced at 16 mm. The high-carbon iron damps vibration and copes better with heat, which helps against judder.
Fitting it
Discs are always changed in axle pairs, and this one comes as a pair in the box. Fit new rear pads at the same time, clean the hub face back to bare metal and check the caliper slide pins. A brake fluid change is often due at the same visit.
