Brembo Brake disc 09.C990.21
282 mm vented front disc for the Ford Focus IV 1.0 EcoBoost
- Art. no.
- 09.C990.21
- EAN
- 8020584311837
- 282mm
- 27mm
- Vented
SKU BRE-09C99021 · EAN 8020584311837
From the central warehouse — delivered next working day · Log in to see your branch’s delivery rounds.
Stock
Central warehouse · 124 · Next day
- Oslo Alnabru20
- Bergen Kokstad41
- Trondheim Tiller0
- Stockholm Västberga9
- Gothenburg Hisings Backa24
- Rotterdam Waalhaven20
Brembo Prime 282 mm x 27 mm vented disc for the front axle of the Ford Focus IV 1.0 EcoBoost. UV-painted hat and edges, 5 holes and a 64 mm centre bore; replace at 25 mm. Sold as a pair, 2 discs per box.
Fits
Vehicles this part is listed for, with position and conditions.
1 vehicle
- Ford Focus IV (HN)1.0 B7DA 125 hpB7DA92 kW922018–2024Front axle
Specifications
Brake disc
- Disc type
- Vented
- Diameter
- 282mm
- Thickness
- 27mm
- Minimum thickness
- 25mm
- Height
- 51mm
- Centering diameter
- 64mm
- Number of holes
- 5
- Coated (anti-corrosion)
- ✓ Yes
- High-carbon cast iron
- ✓ Yes
- Bolts included
- — No
- Wheel bearing included
- — No
- Pieces per pack
- 2
Numbers
OE numbers
Vehicle makers’ own part numbers this part replaces.
| Maker | OE number |
|---|---|
| Ford | 2208066 |
| Ford | 2305503 |
| Ford | JX611125AEA |
| Ford | JX611125AEB |
| Ford | JX6Z1125C |
Cross-references
Equivalent parts from other brands.
| Brand | Art. no. |
|---|---|
| ATE | 24012701031 |
| Bosch | 0986479F81 |
| febi bilstein | 108192 |
| Ferodo | DDF3020C |
| Meyle | 7155210049PD |
| Mintex | MDC2866C |
| Pagid | 56034HC |
| Textar | 92303405 |
| TRW | DF6975 |
| Zimmermann | 250131520 |
Why this one
01
282 x 27 mm
Vented disc, 5 holes, 64 mm centre bore, minimum thickness 25 mm.
02
UV-painted finish
Painted hat and edges keep rust off the hub face and cooling vanes.
03
High-carbon iron
Extra carbon damps vibration and helps the disc handle heat.
04
Sold as a pair
Two discs per box, enough for one axle.
On the job
The job it does
OE-equivalent vented disc for the front axle of the Ford Focus IV 1.0 EcoBoost. New it measures 282 x 27 mm and it must be replaced at 25 mm. The high-carbon iron damps vibration and copes better with heat, which helps against judder.
Fitting it
Discs are always changed in axle pairs, and this one comes as a pair in the box. Fit new front pads at the same time, clean the hub face back to bare metal and check the caliper slide pins. A brake fluid change is often due at the same visit.
